| MODEL | AIMS – MM – 200 |
|---|---|
| Output (Kg / Hour) | 50 To 200 Kg / Hour |
| Rotor Assembly Diameter | Ø 250 mm Approximately |
| Rotor Speed (RPM) | 750 / 1500 / 2300 / 3000 RPM |
| Beaters | 12 Nos. Beaters With Knife & Impact Edges 2 Nos. Scrapper Blades |
| Screen Dimension (mm) | Inner Ø 260 mm X Height 135 mm |
| Starter | “BCH” Make DOL With Reversible Switch |
| Material Charging Height (mm) | 1510 ± 5 mm |
| Material Discharging Height (mm) | 750 ± 5 mm |
| Net Weight (Kg) | 300 Kg |
| Gross Weight (Kg) | 450 Kg |
| Overall Dimension (mm) | 870 mm X 965 mm X 1630 mm |
| Case Dimension (mm) | 1200 mm X 1550 mm X 1860 mm |
| Electric Motor (HP / RPM) | 3 HP / 1440 RPM / Non-Flame Proof (NFLP) |
| Electrical Power Supply | 230 Volts ± 10% Or 440 Volts ± 10% 50 Hz Or 60 Hz / 3 Φ Phase / A.C. Power Supply |
